Revolutionize HVAC Monitoring and Energy Efficiency

Begin your journey toward home Artificial Intelligence driven HVAC monitoring and management

AI processing with HVAIC is a journey.  AI processing for any type of application requires historical data for that application.  Residential HVAC performance and energy usage analysis is no different.  Since energy usage, HVAC equipment and duct design, and home owner thermostat settings are unique, so to is AI processing for each home unique.

HVAIC begins the journey by collecting a myriad of data points typically many times each day for each season of the year.  Data captured is internal from your HVAC equipment and external from the weather outside and environment related to your HVAC air handler.

When sufficient data is captured in our cloud servers, it may then be AI processed for your individual home’s needs. The goal is to use AI to continually evaluate the daily dependencies of outdoor temperatures, HVAC operation and more  to recommend, and with integrated devices such as wireless, smart thermostats, manage your HVAC for energy savings and more comfortable living.

Air Filter Condition
  • HVAIC monitors your air filter’s condition with our Differential Pressure sensor (DP).
  • The DP measures air pressure on both sides of the air filter.  As the filter becomes increasingly clogged, the pressure on the inlet side increases wile on the outlet side it decreases, due to less air passing through.
  • Using a filter beyond its limits will force the fan to work harder to push the same amount of air through the system.  This can increase the risk of expensive hardware failure.
  • An email and/or text alert is sent to the owner when the pressure difference indicates an excessively dirty filter.
HVAC Ambient & Air Output Temperature
  • Which temperatures are saved to the cloud?
    • In-Duct air after heated or cooled.
    • Outdoor temperature at the time of in-duct measurement, and the forecasated highs and lows for that day.
    • The ambient temperature at the HVAC air handler, such as an attic or basement.
  • HVAIC monitors these temperature multiple times daily.
  • The most important indicator of a current or future problem with an HVAC system is a continual shift in the temperature of its output air.
  • Long term records of the relationship between the various temperatures provides valuable insights into the degradation of HVAC performance, and AI processing for energy saving actions or recommendations.
In-Duct Air Flow Rate
  • Probes monitor Cubic Feet/Minute (CFM) air flow inside the duct.
  • Using typical flow rates based on HVAC tonnage, or the owner’s specific HVAC unit, HVAIC compares expected flows to actual flow.
  • Flow too low can lead to too cold or frozen evaporator coils.
  • Flow too fast could lead reduce the ability to dehumidify air, higher blower electricity usage and a noisier system.
Energy Consumption
  • HVAIC measures the amount of AC electrical current being used by your air handler.  This provides relative data of total HVAC energy consumption by season and the temperature ranges.
  • After sufficient historical data is obtained by HVAIC over each day of each season, AI analysis would be able to predict maintenance needs and provide insights into how best to set thermostats for energy reduction.
  • Future plans for HVAIC include integration with one or more thermostat brands to automously adjust thermostats to “comfort zone” temperatures preferred by the home owners.
HVAC Run-Time & Energy
  • In addition to energy, pressure, current and temperature, the run-time of the HVAC (the duty cycle) is stored with each data capture.
  • Current and run-time do not provide KiloWatts of energy use, but relative energy use for each duty cycle.  kW calculations require the voltage draw of each HVAC component.  Each HVAC has uniqure voltage needs and are not available to HVAIC.
  • Since the entire HVAC system never changes, its relative performance from day-to-day is what HVAIC tracks.  Knowing the kW is not relevant to saving energy. Duty cycles are what determine the kW, thus HVAIC’s tracking highs, lows and average values represent whether your energy costs go up or down.
Heat Pumps
  • Heat pumps become less energy efficient below about 40F.
  • When it cannot maintain the set thermostat temperature, auxilary heating coils (AUX) active.  A Google AI search shows that this can result in a 50% or higher energy usage.
  • HVAIC’s monitoring of current can detect the higher current draw and thus track and report the times of use for AUX activation and its duration.
  • An alert or report can be sent to the homeowner.  The homeowner could then lower the thermostat setting at the times shown for AUX use to reduce the frequency and duration of its activation.
Outside Air Temperature
  • Outside air temperature determines inside air temperature changes.
  • Outdoor wireless thermometers are unreliable.  Too often they are placed in areas where sun, heat loss from the home or heat from the outdoor HVAC unit influences the measured temperature.
  • HVAIC records a weather service temerature for the home’s Zip Code whenever HVAIC sends duct air temperature to our cloud.
  • Upcoming HVAC demand can be anticipated by the forecasted high and low temperatures of each day.  As stated in the Energy Consumption tab, with sufficient historical data AI could use the forecasts to optimize HVAC functions to reduce the energy impact related to outdoor air temperature changes.

Transform Your Environment with Smart Monitoring

Contact Us To Get Started

Key Features of Our IoT Monitoring System

Real-Time Temperature Monitoring & Data Capture

Continuously track and store HVAC air handler output temperatures to ensure consistent comfort and monitor for HVAC performance degradation. Current and forecasted outdoor temperatures, and ambient temperature at the air handler are also captured.

Air Filter Cleanliness Alerts

Do you forget to check air filters?Our proprietary differential pressure sensor monitors air pressure on both sides of your air filter. Excessive pressure on the inlet side resultes in instant text/email notifications that the air filter needs attention. HVAIC assures optimal air quality and energy efficiency.

Seasonal Impact on Energy Consumption

Monitor HVAC power usage to track seasonal trends and the impact of heating and cooling on energy consumption. identify savings opportunities related to air filters, thermostat settings and possible fan or other hardware issues.

Begin Your HVAIC Monitoring Experience

Step 1: Have your HVAC service company install HVAIC sensors.

Step 2: Connect HVAIC to your Wi-Fi using our Android or iPhone app.

Step 3: Submit your Account Setup Form to Varitex.

Increase Your Home's Value

Homes with a strong record of HVAC optimal performance & maintenance is of great value to home buyers, and an incentive to purchase your home at a higher price rather than others.

Contact us today for a personalized consultation and discover how we can help you achieve superior air quality, energy efficiency and added home value.

Dealer and manufacturer representation territories are available.
